/ Product catalogue / Domestic ventilation / Residential axial fans / Classic / Stone / 100 Stone TH K turbo
| Unit of measurement | 100 Stone TH K turbo | |
| Connected air duct size | mm | 100 |
| Maximum supply voltage | V | 240 |
| Minimum supply voltage | V | 220 |
| Power supply frequency | Hz | 50/60 |
| Rated power | W | 16 |
| Unit current | A | 0.121 |
| Maximum airflow | m³/h | 113 |
| Rotation speed at 50hz | - | 2500 |
| Sound pressure level LpA at 3 m | dB(A) | 37 |
| Weight | kg | 1.28 |
| Ambient air temperature min | °С | 1 |
| Ambient air temperature max | °С | 40 |
| Ingress protection rating | - | IP24 |
| Trademark | Vents | |||||
| Model | 100 Stone TH K turbo | |||||
| Specific energy consumption (SEC) (kWh/(m²/a)) | Cold | Average | Warm | |||
| -52.5 | A+ | -25.4 | C | -9.9 | F | |
| Type of ventilation unit | Unidirectional | |||||
| Type of drive installed | Single speed | |||||
| Type of heat recovery system | None | |||||
| Maximum flow rate (m³/h) | 113 | |||||
| Electric power input (W) | 16 | |||||
| Reference flow rate (m³/s) | 0.022 | |||||
| Specific power input (SPI) (W/(m³/h)) | 0.142 | |||||
| Control typology | Local demand control | |||||
| Maximum external leakage rates (%) | 2.7 | |||||
| Sound power level (dB(A)) | 57 | |||||
| The annual electricity consumption (AEC) (kWh/a) | Cold | Average | Warm | |||
| 115 | 115 | 115 | ||||
| The annual heating saved (AHS) (kWh/a) | Cold | Average | Warm | |||
| 5536 | 2830 | 1280 | ||||
| ∅D | H | B | L | L1 |
|---|---|---|---|---|
| 99 | 204 | 264 | 86 | 48 |
