Series Vents FYR

Honeycomb filter
APPLICATION

The FYR filter is designed for preliminary and coarse cleaning of outside air from dust in supply ventilation systems of defense structures. The filter is used in three ventilation modes (in peacetime as well).


DESIGN

The product consists of metal meshes that fit tightly together and are fixed in a metal casing. The number and shape of the meshes depend on the required air flow rate.

INSTALLATION

The filter is mounted together with the protective housing KZF or mounted into a ventilation opening. To increase the filtration area, the filters can be connected to each other using an RMF mounting frame.

TECHNICAL DATA
Rated technical data
FYR-1500
FYR-3000
Air flow capacity [m³/h]
up to 1500
up to 3000
Initial max. constant air flow resistance [Pa]
50
100
Purification efficiency [%]
up to 90
Filtering material
Steel mesh
Weight [kg]
5.5
4.2
Filtration class
G4
Maximum allowed dust content at inlet [mg/m³]
1
AERODYNAMIC DATA
