Series Vents Quiet

Axial exhaust fans Quiet feature low noise and high performance
  • Motor type: AC
  • Casing material: Plastic
  • Timer: Turn off timer
  • Humidity sensor
  • Motion sensor
  • Low noise and high performance for fast humidity reduction and unpleasant smell removal in utility spaces.
  • Wide range of models with various options to match different customer needs and demands.
  • High water ingress protection rating IP45 allows to install the fan bathrooms or utility spaces.
  • The casing made of ABC-plastic does not turn yellow or change its original appearance.
  • Energy efficient motor on rolling bearings is rated for long-term operation.
  • Back valve protects the room from drafts.
ADVANTAGES OF THE FAN

Low noise and high performance

High air flow and low noise is ensured via a special impeller of aerodynamic shape and a unique motor design equipped with a rubber anti-vibration connector.

Reliability

The series is equipped with a motor on ball bearings with minimum power consumption. The motor is equipped with overheating protection and is maintenance free for all motor service life. The electronic elements of the fan are covered with special airtight covers, which ensures the unit’s reliability and durability. The fan’s impeller and casing are made of durable high-quality UV-resistant plastic.

No back flow

The specially designed back valve prevents heat losses and back indoor airflow when the fan is off.

Ease of maintenance

The fan can be easily cleaned from dust or dirt. The removable front panel is washable under running water.

Use

  • Residential premises
  • Offices
  • Utility spaces with normal and increased humidity


Colour modifications:

Quiet Red

Quiet Vintage

Quiet Chrome

Quiet Black

Quiet Aluminum Lacquer

MODIFICATIONS
Models of this series can be equipped with extra options:
NameDescription

Icon

Quiet ExtraMotor with increased performance.


Quiet TThe unit is equipped with an adjustable turn-off delay timer. The timer allows to prolong the fan’s operation for 2 to 30 minutes after it is switched off. This allows to reduce humidity and remove unpleasant smell.


Quiet THThe unit is equipped with an adjustable turn-off delay timer and a humidity sensor. The integrated humidity sensor controls the fan’s operation based on the indoor humidity level. If the set humidity level is exceeded, the fan is autonomously triggered and operates until the humidity level is normal. When the normal humidity level is reached, the fan keeps working for until the timer countdown is up and turns off.



Quiet VThe unit is equipped with a pull cord switch to be turned on and off manually.


Quiet VTThe unit is equipped with a turn-off delay timer and a pull cord switch. The integrated turn-off delay timer allows to prolong the fan’s operation from 2 to 30 minutes after it is switched off. This allows to reduce humidity and remove unpleasant smell.



Quiet VTHThe unit is equipped with a pull cord switch, adjustable turn-off delay timer and humidity sensor. The fan can be turned on via the pull cord switch, or automatically after the humidity sensor is triggered. When the set humidity level is reached, the integrated turn-off delay timer starts the countdown.



 Quiet TRThe unit is equipped with a turn-off delay timer and motion sensor. The fan starts when the motion sensor detects motion in its operational zone, triggering the fan. After the motion stops, the turn-off delay timer is turned on.



Lineup Vents Quiet Connected air duct size, mm Maximum airflow, m3/h Sound pressure level LpA at 3 m, dB(A) Motion sensor Pull cord Humidity sensor Electric power input, W Timer
100 97 25 7.5
100 97 25
100 90 25 7
125 185 32 17
125 170 32 13.5
150 315 33 19
